Abstract
Introduction
As a result of increased use of third party add-on transmitters to the Libre system to convert them into CGM, and the use of these with DIY APS systems, a case study to look at accuracy and the effects of calibration on accuracy was undertaken.
Method
Libre was used with MiaoMiao and xDrip to capture two datasets using xDrip auto-calibration and twice daily calibration. The data was uploaded to NightScout for storage and analysis was undertaken using the Diabetes Technology Society Surveillance Error Grid, Modified Bland-Altman plot and standard MARD, Bias and Standard Deviation analyses.
Results
The key result was that when a sensor produced data using the Abbott algorithm that was widely variable from blood tests, it tended to have more variance in the data produced by xDrip than when a sensor behaved well. In addition, as the sensor aged, variance in the final two days on twice daily calibration was greater. Finally, less frequent sensor calibration appeared to result in better accuracy and a negative bias, however confounding factors early in the first calibration cycle may have affected these results.
Conclusions
While frequency of calibration appears to play a part in the accuracy of the data produced using third party add-ons to the Libre, sensor age and sensor native behaviour appear to play more important roles. Users need to be aware of this when they start to use a third party add-on system.
Introduction
As the use of third party add-on transmitters for the Freestyle Libre to convert them into a form of CGM has increased, and as this data has been incorporated into DIY Hybrid Closed Loops (APS), stories of people being hospitalised due to the use of these systems have circulated. At question is the quality of the data being produced and fed into the APS and whether it can be relied on. This is likely to be a combination of the sensors themselves and the calibration approach taken.
Within the Facebook support groups for these systems, a recommended calibration structure has been suggested to try and maintain better data, which suggests frequency of calibration and when and how too calibrate.
This case study uses n=1 data to review how much the output from the Libre with a MiaoMiao transmitter and xDrip software varies compared to blood glucose data and also to Dexcom G6 data under two different calibration models, and whether there are any patterns that can be identified to provide better advice to users of these systems.
Method
In order to look at how the Libre with MiaoMiao and xDrip (Libre) faired, the following configuration was used:
- Libre with MiaoMiao
- xDrip on a standalone phone
- Dexcom G6 using Native settings, started with the non-calibration, coded function. The Dexcom sensor was changed at the end of it’s manufacturer’s recommended life, i.e. 10 days.
- Upload to a single NightScout instance to capture all sensor and manual blood glucose inputs, from two separate collection devices
- All manual blood tests were undertaken on a Contour Next one, which is widely regarded as being the most “accurate” of the available home blood testing meters
For the first seven days of use, the Libre was calibrated using the xDrip “auto-calibration” function, which is supposed to select the most appropriate time to calibrate a sensor, based on a number of factors, including time since last calibration and variation in the glucose entries.
For the second seven days of use, all the previous calibrations were deleted using xDrip’s function for a fake sensor stop. The Libre was then calibrated on an approximately twice daily basis, adhering to the guidance for best practice provided within the Spike facebook group.
During both of these period, multiple manual blood tests were taken that were used only for comparison of data, rather than for calibration. During week one there were 44 manual blood tests. During week two there were 48 manual blood tests.
The data was extracted from the Entries table of the NightScout database, and for each manual blood glucose reading taken, the immediately preceding sensor values were taken for each of the Libre and the G6. This method was used to ensure that any calibration entries for the Libre did not skew the outcomes of a post-manual blood glucose test where they were being used for calibration.
Analysis was then undertaken to determine the MARD and Bias from manual blood test for each of the Libre and the G6, and a standard deviation of MARD values was derived. Surveillance Error Grids and modified Bland-Altman plots were also generated using the Diabetes Technology Society tools.
In addition, data from a previous test of the Libre was used to verify observations from this test, with similar analysis undertaken.
Results
Days one to seven
The results for days one to seven are shown below. Table 1 shows the calculated values for MARD, Bias and Standard Deviation.
On days one and two of use of the Libre sensor, the scans with the Libre reader showed significant difference from blood tests and the Dexcom G6. After this, the sensor “woke up” and aligned more closely with the blood tests.
Figure 2 is the Surveillance Error Grid (SEG) for days 1-7 and figure 3, the modified Bland-Altman plot for the same period.
Days one and two of using this particular sensor appear to show significantly greater variation in values during the period that the scanner was showing disparate data from the manual blood tests. This also shows as relatively wide dispersion in the SEG.
There is a single outlier showing on the SEG, which in the detail of the data showed a Libre value that was approximately double that of the blood test and Dexcom G6 comparators, with an 89% overstatement of the glucose level. It’s worth noting that during the first two days, the mean bias of the Libre was 12% on day one and 17% on day two.
The following days saw the Libre scans align more closely with manual tests and the measures of accuracy become closer to zero.
Days eight to fourteen
The results for days eight to fourteen are shown below. Table 2 shows the calculated values for MARD, Bias and Standard Deviation.
Figure 4 is the Surveillance Error Grid for days 8-14 and figure 5 the modified Bland-Altman plot for the same period.
During days eight to fourteen, the overall MARD from blood was closer than that of days one to seven. As experienced with Abbott’s own data, as the sensor got older, the values for MARD became larger, and this is clear on days 12 to 14. During this second period, the bias on the Libre was to understate rather than overstate glucose levels, unlike the first seven days where they were overstated.
Dexcom G6 Data
For comparison, the Dexcom G6 data is shown below.
As two sensors were used, tabulated data is shown for both, but due to the short period of use of the second sensor, the Surveillance Error Grid and modified Bland-Altman plot were only generated for the first sensor.
Overall, the G6 showed lower variation from blood, however, the data suggests that on a number of days it was not significantly different from the Libre. The standard deviation for the G6 does appear significantly lower than that of the Libre throughout the Libre testing.
December Libre test days one to six
In addition, data was generated from the first six days of a Libre that was previously trialled in December. This is included as the sensor was known to be particularly inaccurate when using the Abbott LibreLink application to scan readings.
A similar dataset for the December sensor was analysed over days one to six of its use, as the trial at that time was not intended for this study, and involved switching the algorithm in use on day six.
The data generated from this sensor tends to show a greater variance in the results, with all three indicators having a wide dispersion. This is reflected in both the SEG and the Bland-Altman plot.
Discussion
Given the concerns relating to use of the Libre in DIY closed loop systems, the questions that arose looked at the calibration techniques people are using (as referenced in this article) and also whether the sensors themselves had a part to play in the outcomes.
Calibration
Looking at the data in this n=1 sample, there appears to be a correlation between frequency of calibration and variation in the readings produced by xDrip. Week one of the Libre sensor shows considerably more variation overall than week two, however, it’s worth taking into account the first two days, where the variation is significantly worse.
Overall during the first seven days, the MARD for the sensor was 13.6%, however, if the first two days are ignored, this drops to 11.9%, which while still higher than that of the second seven days, is a significant reduction, and suggests that well timed calibrations (assuming xDrip is timing the calibrations well) shouldn’t play too great a part in the outcomes.
The second seven days shows a less frequent calibration strategy, with an average of 1.9 calibrations per day. This would appear to hold up the hypothesis that less frequent calibration results in overall better results, however, it’s worth highlighting the last three days of data. Whilst one had four calibrations, the other two didn’t. Whether the calibrations on day 12 affected days 13 and 14 is difficult to say, as accuracy using Abbott’s algorithm is known to get worse towards the end of the sensor, but both appear to have a larger MARD.
In comparison to the Dexcom, the MARD doesn’t seem to be that far off, and in some cases is better, whereas the G6 bias and standard deviation seem to be better. Of note is that the output from the second non-calibrated G6 sensor on days 1-4 appears to be worse.
The other thing of note in week two is that the bias of the system with less frequent calibrations has become negative, compared with a very positive bias in the first week. The standard deviation in the second week is also, generally, less.
When using a CGM system for looping, in general it’s safer to have a negative bias on the data than a positive one as it reduces the risk of overdosing of insulin, and the more widely spaced calibrations on xDrip seemed to tend in this direction, although, it’s possible that even when trying to maintain good calibration standards, there were one or two erroneous ones.
And this brings me on to the comparator data set from December. The frequency of calibration was not too far different from that seen in week two of the initial dataset, however the outcomes appear to be very different. All three indicators suggested a less accurate outcome, even though the calibration model is not too dissimilar, and the number of points compared (48) is similar to the initial dataset.
This raises the question as to what the compounding factors are in accuracy of xDrip/MiaoMiao/Libre.
Sensor native accuracy and age
The key thing in both these data sets is that when the underlying native sensor data is significantly out, using xDrip appears to result in greater divergence.
The first two days of the first dataset show a significant variance, which was during a period of poor performance of the Abbott algorithm, and I suspect, sensor. Likewise, the data from December was also created using a sensor that consistently read well below manual blood glucose readings throughout its life. The resultant accuracy of xDrip, while being better than nothing, was still not especially good.
The following two figures attempt to capture an idea of how variance occurs after a calibration. On each figure, the grey area shows calibrations and the orange line the variance of the Libre data from blood. A one value of the grey are is a calibration. A two value is a blood test with no calibration.
It’s possible to see in both figures that outside the calibration points there appear to be significant variance from blood testing, which users should be aware of. It does appear to show that although in the results, the MARD in the period with less calibration appears better, there seems to be noticeable drift in the data between calibrations. When this is compared to the variation of the Dexcom, it is only when the sensor is behaving poorly that it Libre is significantly worse than the uncalibrated Dexcom. This is shown in Figure 15.
Only two cases have really been covered in this case study. That of automated calibration and that of approximately twice daily calibration. That leaves once daily calibration and less frequent calibration still to be investigated.
It appears that on a well behaved sensor, the less frequent calibration looks to work effectively, but it is harder to comment on a poorly behaved sensor, as those seem to produce poor results with the xDrip/MiaoMiao combination, regardless of the number of calibrations.
Conclusions
The primary purpose of this case study was to address questions about the accuracy, or otherwise, of the Libre, MiaoMiao and xDrip combination, and to understand how much of an impact calibration has. As an n=1 study it is not powered enough to draw widespread conclusions.
Having said that, there appears to be one clear conclusion.
Libre sensors that behave well on the Abbott software and reader generally perform well on the MiaoMiao/xDrip combination. Those that produce very low numbers compared to blood on the Abbott algorithm seem to perform less effectively, and this can include wild varying outputs which are substantially higher than the actual blood value.
The other question related to the effects of calibration on accuracy. This is less clear cut, but it’s fair to say that the period using auto-calibration in xDrip, excluding the first two days of the sensor, generated a greater MARD than the period with calibrations taking place less than twice per day. There is always the possibility that the early calibrations on days one and two skewed this data though.
With this in mind, just off this dataset, calibration once or twice per day appears to be more effective, but with the caveat mentioned above and also bearing in mind that a poorly performing sensor appears to still produce relatively variable results even with a better calibration approach.In addition, as the sensor ages, the results also become less close to the comparative blood tests.
As a result, a further case study will be run looking at once daily calibration and more frequent calibration over a well behaving sensor.
Footnote
Comment is often made about the variability of the manual glucose monitor used. For this particular study, a Bayer Contour Next meter was used as the default across all the glucose testing due to its status as the top rated meter in the Diabetes Technology Society program.
As referenced in the article,
MARD for a blood glucose meter would need to fall within 3.25%-5.25% to guarantee that the meter met the ISO standard, which suggests that fingerpick blood test meters generally produce considerably more accurate results than CGM systems.
